From vineyard and orchard work to gardening, landscaping and municipal applications, maximum productivity and flexibility are basic requirements of a financially successful business. With the 5DS, 5DV, 5DF and 5DF Ecoline series, DEUTZ-FAHR has released a new generation of highly innovative specialist tractors that meet the most exacting demands in terms of productivity and equipment flexibility. The front has been completely redesigned. The engines, cooling systems and fuel tanks are now even more compact under the revamped bonnet.
Improved turning radius thanks to a slimmer front support.
Independent wheel suspension with double wishbone design.
4 wheel braking system and separate brakes valve. Safety in every situation. Agile and smart in fast maneuvers.
PowerShift. Change gears at the push of a button without depressing the clutch
Powershuttle. Change the direction of travel with a single touch
Stop&Go. Start and stop the vehicle in comfort without using the clutch pedal.
Engine efficiency is aided by the large, newly designed cooling package, improved air flow and the Powercore air filter.
Exclusive DOC system. Meet all emissions standards without AdBlue, in a compact solution.
The fuel tank built into the front axle block can be filled with the bonnet closed, while an additional tank is located below the chassis.
Hard at work under the newly designed bonnet are extremely compact three- and four-cylinder FARMotion Stage 3B (Tier 4i) engines. Specially developed for agricultural applications, these common rail engines feature electronic injection with a pressure of 2,000 bar, a new valve concept, enlarged cylinders, a new crankshaft design, an electronic exhaust gas recirculation (EGR) management system and a diesel oxidation catalyst (DOC) system – all of which means they deliver maximum performance and constant torque even at low engine speeds.
The transmission systems of the new DEUTZ-FAHR specialist tractors have also been specially developed to meet the high demands of modern agricultural businesses. Efficiency, versatility and equipment flexibility were the most important criteria here. The three-stage PowerShift transmission with five gears is unique in this tractor class. It provides up to 45 forward and 45 reverse gears. For greater driver comfort, gear changes can be carried out at the push of a button on the gear shift lever without any need to depress the clutch.
The choice of PTO functions is also highly varied. Three PTO speeds are standard as a matter of course at DEUTZ-FAHR: 540, 540 Eco and 1000. The PTO is activated using a button and electro-hydraulic controls. This guarantees a smooth start without jerks. A ground-speed PTO is available as an option.
From vineyards to orchards, from tilling the land to tending and harvesting crops, and from municipal winter service to road and site maintenance – versatility and adaptability is a strength of the new DEUTZ-FAHR specialist tractors. With 2,600 kg lift capacity at the rear (model 5DF: max. 2,800 kg) and 1,500 kg at the front, all possible combinations of equipment can be easily moved. The rear power lift can be electronically controlled if desired.
The new DEUTZ-FAHR front axle concept is unique for specialist tractors, making it a real highlight. Independent wheel suspension with a double wishbone design allows each front wheel to move vertically to a different extent. This results in maximum suspension in all operating scenarios. The spring stroke of each wheel is controlled by an adaptive electro-hydraulic system, ensuring that the wheel contact patch always touches the ground fully.
Cab comfort has not been a mere luxury for specialist tractors for some time. A more pleasant working environment means less severe environmental factors such as cold, heat, dust, crop protection agents and noise – and longer periods of concentration and performance for the driver. The four-post cab of the new specialist tractors meets the highest DEUTZ-FAHR standards. Maximum visibility in every direction, covering all areas relevant to work and safety, is ensured by the one-piece windscreen and all-round glazing. Outside, the cab is compact and slim. There are no sharp edges that could damage crops. Inside, a cutting-edge design and high-quality, light materials create a positive atmosphere.
